Suspended Power-Assisted Manipulator

Suspended Power-Assisted Manipulator: Zero-Gravity Handling for High-Density Workshops

Experience the ultimate in material handling efficiency with our Suspended Power-Assisted Manipulator. Designed to liberate valuable floor space, this system mounts directly to your facility's ceiling or support columns, allowing operators to lift, move, and position loads ranging from 50kg to 500kg with minimal effort. It is the ideal solution for automotive assembly, precision machining, and logistics centers where space optimization is critical.

Why Choose a Suspended System?

Unlike traditional floor-standing manipulators or forklifts, our suspended series offers unique advantages for modern factories:

100% Floor Space Utilization: By utilizing overhead space, we eliminate ground obstacles, allowing for unobstructed forklift traffic and cleaner 5S workshop management.

Enhanced Safety: Separating material handling paths from pedestrian walkways significantly reduces the risk of workplace accidents.

Flexible Coverage: Whether you need a straight line or a complex rectangular area, our track systems are designed to fit your specific layout.

Core Technology & Performance Features

1. Intelligent "Zero-Gravity" Balance Technology

Our manipulators utilize advanced pneumatic or electric servo control systems. The system automatically senses the weight of the workpiece and counterbalances it in real-time.

Effortless Operation: Operators can move heavy loads (up to 500kg) with a force of less than 5N (approx. 0.5kg).

Float Mode: The workpiece can be suspended at any height without drifting, allowing for precise assembly tasks.

2. Precision Positioning System

Equipped with high-quality reducers and braking mechanisms, our manipulators ensure smooth movement without inertia shock.

Repeatability: Positioning accuracy of ±2mm, perfect for inserting parts into molds or machines.

Soft Landing: Prevents damage to delicate workpieces during placement.

Track Configuration Options

We customize the rail system based on your workflow requirements:

Safety & Reliability Standards

Safety is our top priority. JingShi manipulators are built with multiple fail-safes to protect both the operator and the load:

Anti-Drop Protection: In the event of a sudden power or air supply failure, the mechanical self-locking device activates instantly to prevent the load from falling.

Overload Protection: The system will not lift if the weight exceeds the rated capacity, preventing mechanical damage.

Wrong Operation Lock: Prevents the gripper from opening if the load is not fully stabilized or is still in motion.

Durability: Designed with an IP54 protection rating, making it suitable for dusty or humid industrial environments common in manufacturing hubs.

Custom End-Effectors (Grippers)

The manipulator arm is only half the solution; the gripper connects you to your product. We design custom end-effectors based on your workpiece geometry:

Vacuum Suction Cups: Ideal for cardboard boxes, sheet metal, or smooth surfaces.

Mechanical Claws/Clamps: Perfect for engine blocks, tires, or irregular mechanical parts.

Magnetic Lifters: For ferrous metal handling.

Hooks/Balancers: For general lifting of bags or suspended items.

FAQ

Q: What happens if the air supply is cut off suddenly?

A: Our system features a pneumatic check valve and mechanical brake. If the air supply is cut, the manipulator will automatically lock in its current position, ensuring the load does not fall and the arm does not swing wildly.

Q: Can the rail be curved or branched?

A: Yes, we can design switch rails and curved tracks to allow the manipulator to move between different production lines or bypass obstacles.

Q: How difficult is it to install a suspended manipulator?

A: We provide structural calculations and installation drawings. The rail can be mounted to existing building steel beams or supported by independent floor-standing columns if the ceiling structure is not suitable.
